UE5 C++ Logging: Unreal Engine Custom Logger & UE_LOGFMT 📝 # UE5 C++ Logging: Unreal Engine Custom Logger & UE_LOGFMT 📝 #

🖥️ Main Logging Methods in UE5 C++ Code #

Before Unreal Engine 5.2, you were limited to:

• GEngine->AddOnScreenDebugMessage(-1, 5.f, FColor::White, TEXT("Hello Everybody!"));; and
• UE_LOG(LogTemp, Warning, TEXT("Hello Everybody!"));.

The TEXT macro, above, provides C printf style formatting . Modern C++ style guides prefer C++ approaches over printf  though; printf can introduce safety issues  and does not support user-defined types. A good solution (working in older versions of Unreal Engine) is to use std::format (added in C++20) or alternatively, std::print (added in C++23) or a third-party modern formatting library like fmtlib .

If you are using Unreal Engine 5.2 or newer, you can use UE_LOGFMT, with string interpolation, which we see next.

🛸 Modern UE5 Logging with UE_LOGFMT #

Unreal Engine 5.2 and newer offer UE_LOGFMT is available , which has an arguably cleaner API for logging and provides with string interpolation.

Here is a before and after comparison, to see how you can update code to use the new API:

Before (UE_LOG)


UE_LOG(LogTemp, Warning, TEXT("Hello Everybody!"));



After (UE_LOGFMT)


UE_LOGFMT(LogCore, Warning, "Loading `{Name}` failed with error {Error}", Package->GetName(),  ErrorCode);



This will look familiar if you have used any of the string formatting alternatives mentioned above. To sue this new logging macro, just add the following header to source files you use UE_LOGFMT in.


 #include "Logging/StructuredLog.h"



As an alternative, add this header to the project CPP file, like we do below with custom logging.

🪚 Custom UE5 C++ Logging #

Moving on, custom logging, is relatively easy to set up. The advantage of using it, is that you can quickly filter Unreal Engine log messages from your own modules.

To start, create a new CustomLogging.h header file in your project code under YourProject/Source/YourProject/Private/. Create the Private directory if the project does not already have one. Add this code to the new file:


1 #pragma once
2
3 #include "CoreMinimal.h"
4 #include "Logging/StructuredLog.h"
5
6 /* Custom log category */
7 DECLARE_LOG_CATEGORY_EXTERN(YourCustomLogName, Log, All);



Replace YourCustomLogName with whatever you want to appear in the logs against the custom messages. The second and third parameters here are the default severity and which levels of severity to include.

Including Logging/StructuredLog.h (in line 4) will give you access to UE_LOGFMT when you include this header file in other source files.

Making Custom Logs Available to the Engine #

Next, open the project file (YourProject/Source/YourProject/YourProject.cpp), and include your new header and the extra line at the bottom here:


1 // Copyright Epic Games, Inc. All Rights Reserved.
2
3 #include "YourProject.h"
4 #include "CustomLogging.h"
5 #include "Modules/ModuleManager.h"
6
7 IMPLEMENT_PRIMARY_GAME_MODULE( FDefaultGameModuleImpl, YourProject, "YourProject" );
8
9 DEFINE_LOG_CATEGORY(YourCustomLogName);



You might need to refresh the project in the Unreal Engine Editor, for it to pick up the new header. You can now use custom logs, with UE_LOG or UE_LOGFMT in your C++ source files.


1 // ...TRUNCATED
2
3 #include "CustomLogging.h"
4
5 // TRUNCATED...
6
7 Foo::Foo() {
8   UE_LOGFMT(YourCustomLogName, Warning, "Made it here!");
9 }



🙌🏽 UE5 C++ Logging: Wrapping Up #

In this UE5 C++ logging post, we had a look at the options for logging from your C++ code. More specifically, we saw:

• the new UE_LOGFMT macro in action;
• alternatives to UE_LOG string interpolation for working with older versions of Unreal Engine; and
• how you can create custom logs in Unreal Engine, making filtering your own code’s message simpler.

I hope you found this useful. Do let me know if you would like to see more similar content. Also reach out if there is anything I could improve to provide a better experience for you.
